Installation Guide
Installation of the Multi-megapixel Fix cameras
Installation steps
• Unpack the camera
• Remove the sensor's protective cap
• Mount the lens
• Mount the camera on the position fine-tuning panel
• Install the camera in a camera enclosure
• Connect the CAT5 cable
• Connect the power cable
• Connect audio Output (optional)
• Setup the focus
• Setup the IRIS
Remove the protective cap and mount the lens
After unpacking a camera, remove the sensor's protective cap and mount the
lens as soon as possible to prevent sensor soiling. Rotate the lens clockwise to
fix it on the camera. Leave the front lens protective cap until you have installed
the camera in the outdoor camera enclosure! Protect the camera and the lens
from physical impact and moisture!
