Installation Guide
Creating camera setup groups
1. Select Camera setup groups in the Video / Stadium menu!
2. Create a new setup group! Click on the New button, Name the group and
sign it as Default open event group!
3. The previously created camera setups can be seen on the right side in
the Selectable list. Assign those camera setups to the open group, which
have been created for the event! Select them from the list and use the
Add button!
4. Click on OK!
5. Create another new setup group! Click on the New button, Name the
group and sign it as Default closed event group!
6. Assign those camera setups to the closed group, which have been
created for after the event! Select them from the list and use the Add
button!
7. Click on OK!
Creating Panorama cameras
A panoramic camera is a virtual camera in the system, which is built from
several normal multi-megapixel cameras by configuring their position in
the panoramic picture, and stitching them together.
Defining the panorama cameras
1. Open the Panorama camera menu at Video / Setup menu! In this menu
you can virtually assemble the cameras of the panorama camera.
2. Define a new Panorama camera by the New button!
3. Enter a Name and an Export code for the Panorama camera! (The export
code can be any name that contains only letters (A-Z) and numbers (0-9)
Click OK.
4. Assign the appropriate Logipix multi-megapixel cameras to the Panorama
camera! The list of the Selectable cameras can be seen on the right.
60/80
