Installation Guide
3. Suit the Hybrid Extender to the cage nuts and fix it by tightening both
screws!
Connecting the analog cameras
• Connect the BNC cables of the analog cameras to the BNC connectors of
the Hybrid Extender. The connectors can be found at the back of the
Hybrid extender.
Connecting the analog PTZ cameras
• Connect the BNC cables of the analog PTZ cameras to the BNC
connectors of the Hybrid Extender! The connectors can be found at the
back of the Hybrid extender.
• Connect the PTZ cameras serial lines to the RS-485 line of the Hybrid
Extender! The connectors can be found at the back of the Hybrid
extender.
Connecting the CAT5 cables
Connect the CAT5 Ethernet cables' to the RJ-45 sockets of the Hybrid Extender!
The sockets can be found at the back of the Hybrid extender.
Power on
You need to power the Logipix Hybrid Extender using the bundled 12V DC
power supply. The extender will boot immediately upon powering.
