Installation Guide
Automatic registration
There is possibility to import the devices of the system automatically. To
perform this process you have to use a predefined .csv file, wherein the
devices have been listed previously in a given form. The form of the .csv file is
the following:
Name Type assign Network/
channel
Serial IP1 IP2 IP3 IP4 HaveDN HaveABF HaveSATA HaveSound template
The required fields are the Name; Type; and assign. IP1, IP2 (IP2: only in case
of Hybrid Encoders) are strongly recommended fields. The Name is the
device's own name. It should be a unique one in case of LNVR and Hybrid
Encoder. In case of cameras, the names should be unique on every individual
LNVR and Hybrid. Device Types are the following: Camera15MP, Camera2MP,
CameraAnalog, PTZ2MP, PTZAnalog, NVREnterprise, Encoder. To assign the
cameras to an NVR or a Hybrid Encoder an existing device name should be
given. Network/channel is recommended to be given. In case of analog
cameras the fields can be let empty (thus the channel assignment will be
automatic on the free channels of the Hybrid Encoder), but in case of all other
devices, Company Gigabit is the proper adjustment. Serial number is an
optional field, it should be unique if it's given. HaveDN; HaveABF; HaveSATA;
HaveSound fields are optional too and concern only for Logipix cameras. In
case of Logipix 15MP cameras it is recommended to set YES value to the
HaveABF fields. These parameters can be adjusted later during camera
configuration, but this is a faster way to set all Logipix 15MP as cameras with
Auto Back Focus module. Template is optional as well. It can be later adjusted
during camera configuration.
Create a .CSV file (e.g.: in Excel) with the data of the devices based on the .CSV
template above!
1. Open the Control Center software!
2. Select Camera/NVR import and assignment in the Video/Setup menu!
48/80
