Installation Guide
Ethernet Cable Connection
• Connect one end of the CAT5 Ethernet Cable to the PoE Network
Connector of the IP Camera, and the other end of the cable to the
network switch or PC.
NOTE: In some cases, Ethernet Crossover Cable might be needed when
connecting the IP Camera directly to the PC.
NOTE: Check the status of the link indicator and activity indicator LEDs. If the
LEDs are unlit, please check the LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
Setup the position and the viewing angle
• The camera picture can be checked by its analog output.
• Connect the analog output of the camera to the BNC connector of an
analog video setting monitor!
• Set the position of the camera with the console or the housing
positioning options!
• Set the viewing angle and focus using the ring with the “N” and “F”
labels!
17/80
