Installation Guide
Device Power supply
Logipix multi-megapixel fix camera 10-24V DC; 12VDC: 0,7A, 24VDC: 0,35A
Logipix Full HD fix camera PoE
Logipix PTZ camera 20-28V DC, 2.5A
LNVR 100-240VAC, 47-63 Hz single phase; 120VAC:
4.2A; 230VAC: 2.1A
Hybrid extender 12V DC
Appendix B
Bitrates of the cameras in the system
Camera Frame size
[Mbyte]
FPS Bitrate
[Mbit/sec]
Logipix 15 MP camera 2.3 5 100 *
Logipix PTZ camera 0.6 12 60 *
Logipix 2 MP camera 0.1 5 4-8 **
Analog camera 0.06 12 6
* The LNVR records the video stream of the Logipix 15 MP cameras and the Logipix PTZ
cameras using a VRM fail-safe file system which means the frames of the video stream are
stored divided on four HDDs at once. Thus there is no need to mirror the data.
** The video stream of the Logipix 2 MP camera can be recorded in a redundant RAID1
system. In that case every frame is recorded twice to the HDDs, therefore the stream's
bitrate is doubled.
