Installation Guide
NOTE: Check the status of the link indicator and activity indicator LEDs; if the
LEDs are unlit, please check LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
Setup the position and the viewing angle
• The camera picture can be checked by its analog output.
• Connect the analog output of the camera to the BNC connector of an
analog video setting monitor!
• Set the position of the camera with the console or the housing
positioning options.
• Set the viewing angle and focus using the rings of the lenses!
Installation of the Full HD Logipix PTZ cameras
Installation steps
• Unpack the camera
• Drill the holes
• Fix the camera on the Mounting bracket
• Connect the Ethernet cable
• Connect the Power cable
• Check the operation of the PTZ camera
20/80
