Installation Guide
5 GIGABIT Port G20 VMS VLAN – Gigabit port for company
network connection
6 Optical Port 1 Camera VLAN – Optical port for the Logipix
multi-megapixel fix cameras (connected to
the Local Network Switch)
7 Optical Port 2 Camera VLAN – Optical port for the Logipix
multi-megapixel fix cameras (connected to
the Local Network Switch)
8 Power Power on and Power off
9 Reset Reset the LNVR (about 3 min)
10 USB1 / USB2 -
11 Arrows -
12 LCD Display LOGIPIX
13 HDD racks 1-8 Hot swap mobile racks for 3,5” SATA HDDs
Install the HDDs
1. The hot swap HDD mobile racks can be found at the front panel of the
LNVR. Smoothly pull the spring lock of a mobile rack to loosen it, then
pull it out!
2. Carefully place the HDD into the mobile rack and be sure that the printed
label on the HDD is side up!
3. Fix the HDD in the mobile rack by tightening the HDD screws through the
mounting holes! Use at least four screws. The mounting holes can be
found on the side and on the bottom of the mobile rack.
4. Once the HDD is in the mobile rack put it back to its place and gently
push the spring lock to fix it in the LNVR!
5. Repeat the previous steps with all the HDDs!
NOTE: There are four HDD racks in each row at the front panel. Each row forms
a RAID group. Place the HDDs into the LNVR according to the groups. For
example if you are using only 4 HDDs in a LNVR-16-8 fill the first row!
