Installation Guide
• It must have sun shield
Mount the lower part of the positioning panel into the camera house. To install
the Lower part of the panel in an enclosure, follow the steps of the enclosure's
user manual! It is important to install the camera in the enclosure at the best
position. It cannot be neither too close or nor too far from the front glass of
the camera enclosure. The proper position of the camera in the enclosure is
where the distance between the front lens of the camera and the front glass of
the housing is 15mm.
• After the lower part has been installed inside the housing, assembly the
two parts of the positioning panel.
• Put the included three springs on the three setting screws on the lower
part.
• Fit the two parts together by the three setting screws
• Put the included nuts to the setting screws and tighten them to fix the
platform vertically.
• Close the enclosure and fix it at the previously designated point!
• Set the sun shield to a position what can prevent the sunlight to reach
directly the front glass of the enclosure
Connect the CAT5 cable
The connected cable must be the final one which will be used in the network
infrastructure. If you are not using the final CAT5 cable, you may ruin the
camera's final position when rewiring after position and focus setup. Lead the
CAT5 Ethernet cable through the cable gland of the camera enclosure and
connect it with the RJ45 plug to the LAN connector of the camera. The
connector can be found at the back of the camera.
Connect the power cable
The connected cable must be the final one which will be used in the system
infrastructure. Install ferrules for the copper wires of the power supply. Use a
crimping tool to perform this process. Lead the 2×0.5 mm
2
copper wire
