Installation Guide
Dismount the camera from the mounting bracket
• Dismount the enclosure of the camera with the included tool!
• Loosen the fixing bolt with a Phillips screw driver!
• Push the locking tabs at the sides!
• Pull out the camera module from the mounting bracket!
Mount the bracket of the camera
• Drill the proper size four holes for the bracket into the surface!
• Use the included wall-plugs and screws to fix the bracket on the surface!
• Fix the camera module on the bracket!
Power up the Camera
• To power up the IP Camera, please plug the camera’s DC 12V / AC 24V cable into the
power terminal block.
• Alternatively, connect the Ethernet cable to the camera’s PoE port and plug the other end of
the cable into a PoE switch.
NOTE: If using PoE, make sure Power Sourcing Equipment (PSE) is in use in the
network.
Ethernet Cable Connection
• Connect one end of the CAT5 Ethernet cable to the RJ-45 connector of
the IP Camera, and the other end of the cable to the network switch or
PC.
NOTE: In some cases, you may need to use an Ethernet crossover cable when
connecting the IP Camera directly to the PC.
