Installation Guide
Lens Mounting
If C-Mount lens is used, after removing the camera’s plastic cover, you need to
mount the supplied C/CS mount adapter to the camera. Then attach the lens
onto the C/CS mount adapter. Rotate it clockwise. Connect the iris cable to the
rear part of the camera.
Mount the camera
• The camera supports both standing and ceiling consoles.
• Use the appropriate IP level housing for outdoor operation.
• To install the camera in a camera house refer to the user's manual of the housing.
Power up the Camera
• To power up the IP Camera, please plug the camera’s DC 12V / AC 24V
Cable into the power adaptor.
• Alternatively, connect the Ethernet Cable to the camera’s PoE port and
plug the other end of the cable into a PoE switch.
NOTE: If PoE is used, make sure the Power Sourcing Equipment (PSE) is in use
in the network.
