Lorex Player 11: Playing Backed up Video on PC

Lorex Player 11 Interface Overview

About the Advanced Config menu

The Advanced Config menu allows you to select where the screen captures are stored.

To open the Advanced Config menu:

1 Cl

ick the button.

2 Click Select

to change the snapshot save folder. Then select the folder and click OK.

3 Cl

ick OK to save changes.

Click here to open the

Advanced Config menu

Play

Snapshot button

Add file

Remove file

Delete file

Video Window

Hide/reveal

playlist

Next

File

Stop

Previous

File

Open File

Rewind Fast Forward

Select
