15
Using the On-Screen Display
Using the On-Screen Display
Use the system’s graphical on-screen display to navigate menus and configure options and
settings.
1 Dat
e & Time: Displays the date and time on the system
2 Record
Status: Displays the current recording status of the system: C=continuous (normal
recording); M=motion recording; A=alarm recording.
3 Channel n
umber / Channel title: Displays channel number or channel title. To rename the
channel number to a title, see “Configuring Custom Channel Names” on page 33.
C
M
C
C
1. Date & Time
2. Record Status
3. Channel number /
Channel Title
Tip:
If you can’t see your mouse cursor on screen (16-channel model only):
You may have switched output modes from VGA/HDMI to BNC. By default, the DVR
outputs to VGA/HDMI mode at 1024 x 768 resolution.
How To Change Video Outputs:
Front Panel Remote Control
16-Channel
Press and hold
0 for 6
seconds.
Press 0.
