Remote Viewing Using a Web Browser

Upon login, the Remote Surveillance Live tab opens in your browser. The Remote

Surveillance interface is the same on PC or Mac.

1 Navigation Tabs: A

llows you to access the following tabs:

• Liv

e: Watch live video.

• Playback: View

saved video footage.

• Remote Setting:

Configure system and networking options.

• Lo

cal setting: Configure where local files are stored on your hard drive.

• Logout: Exit

s remote viewing.

2 Active Channel List: Displa

ys channels that are currently live.
