Appendix G: Auto Port Forwarding Router Compatibility List

To enable the Auto Port Forwarding feature:

1 In the

Main Menu, click Network.

2 Beside the Auto Port Forwarding drop-down

menu, select Enable.

3 Cl

ick Apply to save your settings.

Netcore NW606 V1.1.77

Netgear MR814 v2

Netgear RP614 v3

Netgear WGT624 v3

Netgear WPN824

PCI MZK-W04NW

PLANET ADE-3400B

Siemens Gigaset SE551

SMC SMCWGBR14-N

Surecom EP-4904SX

Thomson Speedtouch546

Thomson Speedtouch780

TP-Link TL-WR841N V8.0

ZyXEL Prestige 660H-61

Default Chapter3
