Use reference: 1
Use general tolerances:
0
Base folder: C:\LPA_Data
The response shows the current reference trace directory
and the default parameter filename. The “Use Reference:1”
response indicates that the reference trace is being used
(instead of the default parameters file). The “Use general
tolerances: 0” response indicates that the feature specific
tolerances are being used (instead of the general tolerances.)
The “Base folder” response shows the directory where
LightPath data will be saved.
CONFigure:ConfFiGuration
Usage: CONF:CFG {refDir, defParamFile, useRef, useGenTol,
baseFolder}
Description: Sets the current LightPath
configuration.
The parameter refDir specifies the directory containing the
reference trace. The name must be in quotes if it contains
any spaces. If this parameter is specified as “”, the current
reference trace will be retained.
The parameter defParamFile specifies the default parameter
filename. The name must be in quotes if it contains any
spaces. If this parameter is specified as “”, the current
parameter file will be retained.
The parameter useRef specifies whether acquired traces are
compared to the reference trace or to the default parameter
file. A value of 1 indicates that the reference trace should
be used. A value of 0 indicates that the default parameter
file should be used.
The parameter useGenTol specifies whether acquired traces
are compared to a reference trace's general tolerances or to
its
feature-specific tolerances. A value of 1 indicates that the
general tolerances should be used. A value of 0 indicates
that the feature-specific tolerances should be used. This
parameter is not meaningful if setting useRef to 0.
The parameter baseFolder specifies the base folder where
LightPath data files will be saved.
