198 Chapter 9
Maintenance
3 Turn the protective cap counterclockwise to remove it. Gently insert one of the
supplied mini swabs, as shown below. Twist the swab in one direction, and then
remove. Discard miniswabs after single use.
Figure 9-1. Remove the protective cap. Gently insert supplied mini swab, rotate in
one direction, then remove.
4 Replace the protective cap to protect the connector.
Cleaning the Case
Clean the case by wiping it with a soft cloth dampened with water or a mild, non-
abrasive cleaning fluid such as window cleaner.
Caution
Do not spray any fluid directly on case surfaces. It may
9
seep into the interior of the case and damage components.
Replacing Fuses
The fuse drawer is located on the power module on the instrument case back panel:
