Pg 7
Figure 3 – MAC155 Probe Compressed Air Input
It is required to provide clean, dry, instrument air for the compressed air
input. Failure to do so may result in damage to the moisture sensor which
is not covered under the warranty.
LWhen first installing the unit the air lines should be purged before
connecting to unit.
Air Input Fitting
