Pg 35

If dust or particles are blown off the filter element using compressed air, a dust

cloud will form. Eye protection should be worn and care should be taken not to

breathe in the dust.

If solvents other than water are used, they should not be blown from the filter

with compressed air, but should instead be allowed to evaporate in a well

ventilated area far removed from sources of ignition. If compressed air were

used, a highly explosive cloud of mist and vapor would be generated. This could

also cause a hazard if inhaled or if it were to get into the eyes.

Figure 22 – MAC155 Probe Filter Parts

Figure 23 – Probe Filter Partially Assembled

Compression

Spring

Filter Cover

Filter Element

Filter

Retaining

Bushing
