MAC155 Rev. 12 ©Copyright MAC Instruments 2005. All Rights Reserved.
Pg 24
Figure 14 – Water Level Sensor Location
The water level is monitored by a water level sensor. If the water level falls
below a minimum level, the “Low Water” alarm will be activated.
L The “Low Water” alarm signal indicates that service to the water tank is
required.
WATER FILLING / FLUSHING KIT
A funnel and drip prevention tube are supplied with the MAC155 to be used
when filling the tank. This funnel should not be used for any other purpose, and it
