©Copyright MAC Instruments 2005. All Rights Reserved. MAC155 Rev. 12
Pg 39
PERISTALTIC PUMP TUBING REPLACEMENT
Figure 24 – Peristaltic Pump stand-in Tubing
6. Remove the two screws holding the plastic head assembly, and
remove the assembly from the motor.
Figure 25 – Peristaltic Pump Assembly
Remove Screws
Pump Housing
Pump Motor
