©Copyright MAC Instruments 2005. All Rights Reserved. MAC155 Rev. 12
Pg 41
9. Reassemble the housing. Insert the two screws through the holes in
the housing and place the two black rubber washers over the ends of
the screws to hold them in place.
10. Mount the housing onto the motor. Note that the flat on the motor
shaft, must line up with the internal flat in the cam wheel. Tighten the
screws.
