Mackie DL Series Reference Guide

Mackie DL806 and DL1608 Reference Guide
154
Specications Continued...
Analog Inputs
Connectors: .................................................................................. 1-12:XLRBalanced,13-16:ComboXLR/TRSBalanced[DL1608]
1-4:XLRBalanced,5-8:ComboXLR/TRSBalanced[DL806]
XLRMicPre: .....................................................................................................................................................................................................Onyx
Input Impedance: ............................................................................... 1-12: 3k , 13-16: 3 k mic[XLR],30k line[1/4"][DL1608]
1-4: 3k , 5-8: 3 k mic[XLR],30k line[1/4"][DL806]
Max Input Level: .............................................................................................................................................................................XLR:+21dBu
1/4":+30dBu
Gain: ............................................................................................................................................................................................. XLR: 0 to 60 dB
1/4":–20to40dB
48VPhantomPower(XLR): ............................................. 48VDC,10mAmaxpermic,withuptoeightsimultaneously[both]
5mAmaxpermic,withupto16simultaneously[DL1608]
Analog Main Out L/R
Connectors: .....................................................................................................................................................................................XLR Balanced
Output Impedance: .....................................................................................................................................................................................600
Max Output Level: .................................................................................................................................................................................. +21dBu
Analog Aux Sends
Connectors: .................................................................................................................................................... 1/4"TRSImpedanceBalanced
(Supports balanced / unbalanced operation)
Output Impedance: ........................................................................................................................ 240 Balanced, 120 Unbalanced
Max Output Level: .................................................................................................................................................................................. +21dBu
Analog Headphone Out
Connector: ....................................................................................................................................................................................1/4"TRSStereo
Max Output Level: .........................................................................................................................................................+18.0dBuinto600
+19.5dBumaxinto100k
