Mackie DL Series Reference Guide

Mackie DL806 and DL1608 Reference Guide
67
Vintage EQ Gain and Frequency
ThegainforeachEQbandmaybechangedbydraggingup[increasesgain]anddown[decreasesgain]
over the knob until the desired gain has been achieved. The gain may be changed by approximately
±15dB...it’svintage,sonothingisexact! Double-tap a gain knob to reset its gain to zero. Each EQ band
here has a vertical row of frequency buttons located underneath its gain knob. Simply tap the frequency
button you desire for each band. The frequency ranges from 35 Hz to 15 kHz. The gain (but not the
frequency) may also be manually entered via the current parameter display.
Low
The low EQ provides approximately 15 dB of boost or cut from 35 Hz to 330 Hz. This frequency
represents the punch in bass drums, bass guitar, fat synth patches, and some really serious male
singers who eat raw beef for breakfast.
Mid
The mid EQ provides approximately 15 dB of boost or cut from 360 Hz to 7.2 kHz. Frequencies aected
typically include guitar, piano and the fundamentals and harmonics of many instruments.
Wide / Narrow
Below the mid EQ vertical frequency strip is a wide / narrow button. Generally speaking, wide is
used for broad tone-shaping while narrow is more precise. Select what you would prefer the mid
 frequencyQ[bandwidth]tosoundlike.
High
 ThehighEQprovidesapproximately15dBofboostorcutfrom3.3kHzto15kHz.Useittoadd
sizzle to cymbals, an overall sense of transparency, or an edge to keyboards, vocals, guitar
and bacon frying. Select a lower frequency to reduce sibilance or harsh treble.
Vintage EQ at a Glance
Parameter Low Value Limit High Value Limit Default
PolarityInvert O On O
HPFEnable O On On
HPFFrequency O•50Hz•80Hz•160Hz•300Hz 80 Hz
HPFSlope O 300 Hz 18 dB/octave
EQ Enable O On On
High Shelf Gain –15 dB +15dB 0 dB
High Shelf Freq 3.3kHz•4.7kHz•6.8kHz•10kHz•15kHz 10 kHz
Mid Gain –15 dB +15dB 0 dB
Mid Freq 360Hz•700Hz•1.6kHz•3.2kHz•4.8kHz•7.2kHz 360 Hz
Mid Q Wide Narrow Narrow
Low Shelf Gain –15 dB +15dB 0 dB
Low Shelf Freq 35Hz•60Hz•110Hz•220Hz•330Hz 60 Hz
