Mackie DL Series Reference Guide

Mackie DL806 and DL1608 Reference Guide
61
Modern EQ Gain, Frequency and Q [Bandwidth]
The gain and frequency may be changed by moving any of the four numbered balls (representing
each band) until the desired sound has been achieved. Moving a ball vertically changes the gain
by up to ±15 dB. Moving a ball horizontally changes the frequency, ranging from 20 Hz to 20 kHz.
ThereisaShelf/Belloptionforbands1and4anditisdescribedindetailonpage63.Q[bandwidth]
is changed by pinching the ball. Double-tap an EQ ball to reset its gain to zero.
Low Shelving – Band 1
The low EQ provides up to 15 dB of boost or cut from 20 Hz to 20 kHz. This frequency represents
the punch in bass drums, bass guitar, fat synth patches, and some really serious male singers who
eat raw beef for breakfast.
Low-Mid Peaking – Band 2
The low-mid EQ provides up to 15 dB of boost or cut from 20 Hz to 20 kHz. Frequencies aected
typically include the male vocal range as well as the fundamentals and harmonics of many
lower-timbred instruments.
Gain (+)
Gain (–)
Frequency (+)Frequency (–)
Gain (+)
Gain (–)
Frequency (+)Frequency (–)
