Mackie DL806 and DL1608 Reference Guide
170
2. Aux Send Linking [page55oftheReferenceGuide]
Two neighboring mono aux sends may be linked together into a single stereo aux. This is ideal for using
in-ear monitors or other stereo output destinations such as broadcast feeds, recording devices and more.
When linked, the level control, graphic EQ and output compressor/limiter are adjusted with a single set
of controls.
AuxsendsmaybelinkedandunlinkedinMyFader,too.
3. Aux/FX Send Conguration Menu [pages48-49oftheReferenceGuide]
There are three additions to the aux/FX send conguration menu:
Pre DSP —InadditiontoPreFaderandPostFader,usersmay
nowchoosePreDSPastheauxsendsource.PreDSPisideal
when using the auxes for monitor mixes and you want EQ, gate
andcompressioninthemainmix,butnotthemonitors.PreDSP
is available on all auxes, but not the FX sends.
Use LR Mute —WhenUseLRMuteisenabled,theauxsends
sharethesamemutesastheLRmainmix.WhenUseLRMute
is disabled, users can control aux mutes and main mix mutes
independentlyforeachchannel.UseLRMuteisavailableonall
auxes and FX.
Use LR Pan [Stereo Auxes only] —WhenUseLRPanisenabled,
the aux pans share the same pans as the LR main mix. When
UseLRPanisdisabled,userscancontrolauxpansandmainmix
pansindependentlyforeachchannel.UseLRPanisavailableon
stereo linked auxes, but not on FX.
Additionally,FXsendsmaynowbeconguredasPreFaderformoreadvancedFXneeds.
Unlinked Linked
