82
[15] WINCH 2 SPEED SELECTOR SWITCH
• Perform raising and lowering operation at high speed only under a no load condition and
without hoisting a load.
Raising and lowering operation of a hoisted load at high speed may cause serious
physical injury due to the machine tipping, breakage or dropping of a load.
• If the weight of a hoisted load is "0.5t" or more, the speed does not become high even
when the winch 2 speed selector switch is operated.
If the weight of a hoisted load is "0.2
t" or less, it is possible to perform raising and
lowering operation in high, but such operation may cause serious physical injury due to
machine tipping, breakage or dropping of a load. Therefore, avoid such operation as much
Use this switch when changing the speed at the time of
raising and lowering operation of the winch.
The lever switch can change the speed between "1st
speed" and "2nd speed".
• High speed (2nd speed): Raising and lowering speed is
increased.
• Low speed (1st speed): The speed returns to the normal
raising and lowering speed.
Check that when the lever switch is pressed, the monitor
display also changes.
When the number of wire falls of the moment limiter is set to
"one fall", the speed does not become high even if this
switch is placed in the "High speed (2nd speed)" position.
The speed is fixed to "Low speed (1st speed)".
