Magnetek 2001-G+M - Option Parameters; Pulse Generated (PG) Control

IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-45
Option Parameters
• F1 Pulse Generated Option Set Up
Pulse Generated (PG) Control
The following option parameters are used to set and control the action for the Pulse Generated (PG)
input and output, including overspeed detection. These parameters become visible when the pulse
generator function (H06.01) is set to 03 and the control method is set to OLV (A01.02 = 02).
Parameter
Code Name Function Range
Initial
Value
Access
Level
F01.02 Pulse Feedback Loss Stopping Method for PG
disconnection
00–03 01 Adv
00 Decel to Stop (by B05.02)
01 Coast to Stop
02 Fast Stop (by B05.08)
03 Alarm Only
F01.03 Operation at Overspeed Stopping Method for PG
Overspeed
00–03 01 Adv
00 Decel to Stop (by B05.02)
01 Coast to Stop
02 Fast Stop (by B05.08)
03 Alarm Only
F01.04 Operation at Deviation Stopping Method for PG at
excessive deviation
00–07 05 Adv
00 @ speed agree - Decel (by
B05.02)
01 @ speed agree - Coast to
Stop
02 @ speed agree - Fast Stop
(by B05.08)
03 @ speed agree - Alarm only
04 @ Run - Decel to Stop (by
B05.02)
05 @ Run - Coast to Stop
06 @ Run - Fast Stop (by
B05.08)
07 Alarm only (Dev-1 and Dev-
2 Alarm)
F01.08 Overspeed Detection
Level
PG Overspeed Detection Level 0 105 Adv
F01.09 Overspeed Detection
Time
PG Overspeed Detection Time 0.0–2.0sec 0.0 Adv
F01.10 Excessive Speed
Detection Level
Excessive Speed Deviation
Level
0–50% 10 Adv
F01.11 Excessive Speed
Detection Time
Excessive Speed Deviation
Detection Time
0.0–10.0sec 0.3 Adv
F01.14 PGO Detection Time PGO Detection Time 0.0–10.0sec 0.5 Adv
