External Fault Response Selection
It is sometimes desirable to have at least one external fault input to the drive. To properly program a
multi-function input (H01.01 to H01.07) for this purpose an external fault response must be selected.
The table below shows the possible selections for an external fault response.
(1) N.O. = normally open contact; N.C. = normally closed contact
(2) Uses B05.08 timer
Table 5-7:
External Fault Selection
Input Level
Selection Detection Method External Fault Action
MFI Setting
Result
N.O.
(1)
N.C.
(1)
Always
During
Run
Ramp to
Stop Coast to Stop Fast-stop
(2)
Alarm
Only
20
24
28
2C
22
26
2A
2E
21
25
29
2D
23
27
2B
2F
