Operator Parameters
The keypad parameters give the ability to show a variety of information such as frequency reference,
motor current, input and output terminal status, along with fault trace information. Information
displayed can be customized to meet your crane and hoist application. Below is a list of parameters
covered in this section.
• O1 Monitor Selection
• O2 Keypad Key Selection
• O3 Clear History
• U1 Monitor
• U2 Fault Trace
• U3 Fault History
• U4 Maintenance
• U6 Motor Control Monitor
Monitor Selection
The top level in the operator mode allows the viewing of four monitor variables. They are Fref, Fout,
Iout, and User-Selected monitor. This user-selected monitor can be selected from the following table.
Parameter
Code Name Function Range
Initial
Value
Access
Level
O01.01 User Monitor Selection Assigns one of the following monitor
parameters to be displayed upon
power-up. For example, set O01.01 =
403 to display U04.03.
104–638 106 Adv
104 Control Method
105 Motor Speed - OLV ONLY
106 Output Voltage
107 DC Bus Voltage
108 Output Power
109 Torque Reference - OLV ONLY
110 Input Terminal Status
111 Output Terminal Status
112 Operation Status
113 Elapsed Time
114 FLASH ID
115 Terminal A1 level
116 Terminal A2 level
120 Output Frequency After Soft
Start
128 CPU ID
134 OPE Detected
139 Memobus Comm Error Code
152 Maintenance Timer
154 Input Pulse Monitor
162 Not Used
