IMPULSE•G+ Mini Advanced Instruction Manual - March 2014
1-5
IMPULSE•G+ Mini General Specifications
230V Class
460V Class
230V and 460V Classes
Specification Specification Values and Information for Each 230V-Class Model
2001
2003
2005
2008
2011
2017
2025
2033
2047
2060
Rated current (A) 1.6 3.0 5.0 8.0 11.0 17.5 25.0 33.0 47.0 60.0
Capacity (kVA) 0.6 1.1 1.9 3.0 4.2 6.7 9.5 12.6 17.9 22.9
Specification Specification Values and Information for Each 460V-Class Model
4001
4002
4003
4004
4009
4014
4018
4024
4031
Rated current (A) 1.2 1.8 3.4 4.8 9.2 14.8 18.0 24.0 31.0
Capacity (kVA) 0.9 1.4 2.6 3.7 7.0 11.3 13.7 18.3 23.6
Specification Specification Value and Information for All Models
Certification UL, cUL, CSA, CE, TüV, RoHS
Rated input power supply volts & freq 3-phase 200–240V or 380–480V; 50/60 Hz
Allowable input voltage fluctuation +10% or -15% of nominal
Allowable input frequency fluctuation ±5% of nominal
Control method Fully digital; sine-wave, pulse-width–modulated
Maximum output voltage (VAC) Max output voltage 3-phase, 200–240V; 380–480V (proportional to input voltage).
Rated frequency (Hz) Up to twice motor nameplate RPM (Swift-Lift) 60 Hz standard (150 Hz, consult factory)
Output speed control range 40:1 - V/f, 100:1 - Open Loop Vector (OLV)
Output frequency accuracy 0.01%—with digital reference command
0.1%—with analog reference command; 10 bits/10V
Frequency reference resolution Digital: 0.01 Hz; analog: 0.03 Hz (at 60 Hz)
Output frequency resolution 0.01 Hz
Overload capacity 150% of rated output current of the drive for 1 minute
Remote frequency reference sources 0–10VDC (2k); 4–20mA (250); serial (RS-485)
Accel/decel times 0.0 to 25.5 seconds - 1 set; 0.0 to 6000.0 - 3 sets; 8 parameters are independently adjustable
Braking torque 150% or more with dynamic braking
Motor overload protection UL recognized electronic thermal overload relay; field-programmable
Overcurrent protection level 200% of drive rated current
Circuit protection Ground fault and blown-fuse protection
Overvoltage protection level Approximately 410VDC (230V Class), 820VDC (460V Class)
Undervoltage protection level Approximately 190VDC (230V Class), 380VDC (460V Class)
Heatsink overtemperature Thermostat trips at 184–249°F (90 - 121°C), dependent on drive capacity
Torque limit selection Separate functions for FORWARD, REVERSE, REGEN.; all selectable from 0–300%
Stall prevention Separate functions for accel, decel, at-speed, and constant horsepower region
