IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-77
Automatic Reset
When a fault occurs during operation, the IMPULSE•G+ Mini can be programmed to automatically
reset the fault and restart operation.
Parameter
Code Name Function Range
Initial
Value
Access
Level
L09.01 Auto Reset Select Activates the fault auto-reset
function.
00, 01 01 Basic/Adv
00 Disabled
01 Enabled
L09.02 Auto Reset Attempts Sets the number of reset
attempts.
Reset attempt counter is
returned to zero if no faults
occur within a ten minute
period.
00–10 03 Basic/Adv
L09.03 Auto Reset Time Sets the reset starting time 0.5–180.0 sec 0.5 Basic/Adv
L09.04* Auto Reset Flt Sel 1 Reset Fault Select 1. 0000–FFFF 0001 Basic/Adv
L09.05* Auto Reset Flt Sel 2 Reset Fault Select 2. 0000–FFFF E000 Basic/Adv
L09.06 Output Contact (MC-MB-
MA) Select
Fault contact operation during
reset attempts
00, 01 01 Basic/Adv
00 No Fault Relay
01 Fault Relay active
* To program constant L09.04 and L09.05, refer to the example on the following page and follow steps 1
through 4:
1. Assign a “1” to each fault code that you wish to enable the auto reset.
2. Assign a “0” to each fault code that you wish to disable the auto reset.
3. Convert all digits (1 to 4) from binary to hex.
4. Program L09.04 and L09.05 by entering the hex number obtained from step 3.
