IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-3
Application
The application parameters control the acceleration and deceleration characteristics, as well as any
preset frequencies the system will require for operation. Application parameters included in this
section are listed below:
• B1 Preset References
• B2 Reference Limits
• B3 Sequence/Reference Source
• B5 Acceleration/Deceleration
• B8 Jump Frequencies
Preset Reference
Parameter
Code Name Function Range
Initial
Value
Access
Level
B01.01 Frequency Reference 1 Sets the frequency of
Minimum Speed/Speed 1.
0.00–150.00 Hz** 15.00* Basic/Adv
B01.02 Frequency Reference 2 Sets the Speed 2 frequency. 0.00–150.00 Hz** 30.00* Basic/Adv
B01.03 Frequency Reference 3 Sets the Speed 3 frequency. 0.00–150.00 Hz** 60.00* Basic/Adv
B01.04 Frequency Reference 4 Sets the Speed 4 frequency. 0.00–150.00 Hz** 0.00* Basic/Adv
B01.05 Frequency Reference 5 Sets the Speed 5 frequency. 0.00–150.00 Hz** 0.00* Basic/Adv
B01.06 Frequency Reference 6 Sets the Speed 6 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.07 Frequency Reference 7 Sets the Speed 7 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.08 Frequency Reference 8 Sets the Speed 8 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.09 Frequency Reference 9 Sets the Speed 9 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.10 Frequency Reference 10 Sets the Speed 10 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.11 Frequency Reference 11 Sets the Speed 11 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.12 Frequency Reference 12 Sets the Speed 12 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.13 Frequency Reference 13 Sets the Speed 13 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.14 Frequency Reference 14 Sets the Speed 14 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.15 Frequency Reference 15 Sets the Speed 15 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.16 Frequency Reference 16 Sets the Speed 16 frequency. 0.00–150.00 Hz** 0.00* Adv
B01.17 Jog Reference Sets the Speed 17 frequency. 0.00–150.00 Hz** 0.00 Adv
B01.18 Reference Priority Determines whether the
digital or analog frequency
reference is used.
00* Basic/Adv
00 Digital Ref Only
01 Analog Ref Only
02 Higher Ref Sel
NOTE: When using Higher
Ref Sel, 2-Step Infinitely
Variable should NOT be used
for a Speed Reference setting
in parameter A01.04. The
two functions are not
intended to work in
conjunction.
* Initial value is determined by X-Press Programming (Table 4.1-4.2).
**Maximum frequency above 150 HZ is available, consult Magnetek.
