Table 5-1: Multi-Step Speed Processing by Multi-Function Input (B01.01 ~ B01.16)
Speed Reference
Forward/Reverse
H01.01 = 80
H01.02 = 81
Multi-Step Speed 2
H01.01 ~ .06 = 00
Multi-Step Speed 3
H01.01 ~ .06 = 01
Multi-Step Speed 4
H01.01 ~ .06 = 02
Multi-Step Speed 5
H01.01 ~ .06 = 03
Fwd/Rev Jog-Fwd/
Rev Inch H01.01~06
= 15, 16, 17, 18
STOP Off--------Off
B01.01
Speed Ref 1
On Off Off Off Off Off
B01.02
Speed Ref 2
On On Off Off Off Off
B01.03
Speed Ref 3
On On On Off Off Off
B01.04
Speed Ref 4
On On On On Off Off
B01.05
Speed Ref 5
On On On On On Off
B01.06
Speed Ref 6
On Off On Off Off Off
B01.07
Speed Ref 7
On Off On On Off Off
B01.08
Speed Ref 8
On Off Off On Off Off
B01.09
Speed Ref 9
On Off On On On Off
B01.10
Speed Ref 10
On Off Off On On Off
B01.11
Speed Ref 11
On Off Off Off On Off
B01.12
Speed Ref 12
On On Off Off On Off
B01.13
Speed Ref 13
On On On Off On Off
B01.14
Speed Ref 14
On Off On Off On Off
B01.15
Speed Ref 15
On On Off On Off Off
B01.16
Speed Ref 16
On On Off On On Off
