IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-6
Sequence/Reference Source
B03.01 and B03.02 determine the source from where the frequency reference and RUN command
are generated.
Stopping Method
B03.03 selects the stopping method suitable for the particular application.
Parameter
Code Name Function Range
Initial
Value
Access
Level
B03.01 Reference Source Source from where the frequency
reference is generated.
00–02, 04 01 Basic/Adv
00 Digital Operator Digital operator (Keypad). Basic/Adv
01 Terminal Control circuit terminal Basic/Adv
02 Communication Memobus Serial Communication Adv
04 Pulse Input Pulse Input Adv
B03.02 Run Source Source from where the RUN
command is generated.
00–02 01 Basic/Adv
00 Digital Operator Digital operator (Keypad). Basic/Adv
01 Terminals Control circuit terminal. Basic/Adv
02 Communication Memobus Adv
Parameter
Code Name Function Range Initial Value
Access
Level
B03.03 Stop Method Determines stop method. 00–02, 04 * Basic/Adv
00 Decel to Stop
(A1-03=0)
Used to stop when motion
is traverse
(Fig 5-2 & 5-3)
Basic/Adv
01 Coast to Stop
(A1-03=1)
Used to stop when motion
is hoist
(Fig 5-4 & 5-5)
Basic/Adv
02 DC Injection (Fig 5-6 & 5-7) Adv
04 Decel w/ Timer
(traverse only)
(Fig 5-8, 5-9, & 5-10) Adv
* Initial value is determined by X-Press Programming
WARNING
Because of the additional potential hazards that are introduced when any drive is operated
locally, we advise you to avoid operating it this way. If you do operate the drive locally, be
aware that the crane or hoist will move when you press the RUN button. If you have questions,
contact Magnetek.
