Magnetek 2001-G+M - Analog Outputs

IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-57
Analog Outputs
The IMPULSE•G+Mini has two analog outputs for the external monitoring of drive conditions.
Parameter
Code Name Function Range
Initial
Value
Access
Level
H04.01 Terminal AM Select Assigns one of the following
functions for analog output
Terminal AM.
101–162 102 Adv
101 Frequency Reference
102 Output Frequency
103 Output Current
105 Motor Speed
(OLV only)
106 Output Voltage
107 DC Bus Voltage
108 Output Power
(calculated in HP)
109 Torque Reference
(OLV only)
115 Term A1 Level
116 Term A2 Level
120 SFS Output
154 Input Pulse Monitor
162 Not Used
H04.02 Terminal AM Gain Gain multiplier for Terminal AM
analog output signal
-999.9–999.9% 100.0 Adv
H04.03 Terminal AM Bias Bias multiplier for Terminal AM
analog output signal
-999.9–999.9% 000.0 Adv
