IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-56
Parameter
Code Name Function Range
Initial
Value
Access
Level
H03.09 Terminal A2 Signal Select Selects the signal level for Terminal
A2
00–03 02 Basic/Adv
00 0VDC ~ 10VDC (switch S2 must be in the “V” position) Basic/Adv
02 4 to 20mA (switch S2 must be in the “I” position) Basic/Adv
03 0 to 20mA (switch S2 must be in the “I” position) Basic/Adv
NOTE: Switch between current or voltage inputs by using (S2)
switch on the main board
H03.10 Terminal A2 Select Assigns one of the following
functions for the analog input
Terminal A2.
00–1F 00 Basic/Adv
00 Frequency Bias Basic
01 Frequency Gain Adv
02 Aux Speed Reference 1 Adv
03 Aux Speed Reference 2 Adv
04 Output Voltage Bias Adv
07 OT/UT Detection Level Overtorque Detection Level Adv
0E Motor Temperature Used in conjunction with L01.03,
L01.04 and L01.05
Adv
0F Not used Not Used Basic/Adv
10 Forward Torque Limit Adv
11 Reverse Torque Limit Adv
12 Regen Torque Limit Adv
15 FWD/REV Torque Limit Adv
1F Not Used Not used Adv
H03.11 Terminal A2 Gain Gain multiplier for terminal A2
analog input signal
-999.9 –
999.9%
100.0 Basic/Adv
H03.12 Terminal A2 Bias Bias multiplier for terminal A2
analog input signal
-999.9 –
999.9%
000.0 Basic/Adv
H03.13 Analog Input Filter Time
Constant
Analog input filter average time;
analog delay time constant between
Terminals A1 and A2
0.00-2.00sec 0.03 Basic/Adv
