Digital Outputs
The IMPULSE•G+ Mini has three multi-function control outputs (one relay, two open collector) for
indicating various conditions. The following table lists the function selections for the multi-function
contact outputs and indicates the control modes during which each function can be enabled.
Parameter
Code Name Function
Reference
Page
Number Range
Initial
Value
Access
Level
H02.01 Output Contactor (MC-
MB-MA) select
Digital Output 1 Function -- 000–1FF 000 Basic
H02.02 Output Terminal P1 Select Digital Output 2 Function -- 000–1FF 000 Basic
H02.03 Output Terminal P2 Select Digital Output 3 Function -- 000–1FF 00F Basic
000 Brake Release Closed when the drive
provides a voltage or
frequency is output
-- Basic/Adv
001 Zero Speed Closed when the output
frequency is below B02.02 or
D01.01
-- Basic/Adv
002 Fref/Fout Agree 1 Closed when Frequency
Reference and Frequency
Output agree
-- Adv
003 Fref/Set Agree 1 Closed when Output
Frequency Reference equals
L04.01
5-72 Adv
004 Freq Detect 1 Closed when the output
frequency is < L04.01.
5-72 Basic/Adv
005 Freq Detect 2 Closed when the output
frequency is > L04.01.
5-72 Basic/Adv
006 Inverter Ready Closed when an inverter is
not in a fault state
-- Adv
007 DC Bus Undervolt Closed when DC Bus voltage
drops below UV trip point
-- Adv
008 BaseBlk N.O. Closed when the inverter is
not outputting voltage
-- Adv
009 Frequency Reference
Source
Closed when the frequency
reference is input from the
digital operator (O02.01)
5-87 Adv
00A Local Operation Closed when the RUN
command is input from the
digital operator.
-- Adv
00B Trq Det 1 N.O. Closed when torque > L06.02 5-75 Basic/Adv
00DDB Overheat Closed when inverter displays
“RH” or “RR” fault
-- Adv
00E Fault Closed during a major fault. -- Basic/Adv
00F Not Used No function -- Basic/Adv
010 Minor Fault Closed during minor fault or
alarm
-- Adv
011 Reset Cmd Active Closed when a reset
command is present on the
terminals
-- Adv
012 Timer Output See Timer function output 5-32 Adv
013 Fref/Fout Agree 2 Closed when output frequency
= frequency reference
5-72 Adv
014 Fref/Set Agree 2 Closed when output frequency
= L04.03
5-72 Adv
