IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-55
Analog Inputs
The IMPULSE•G+ Mini has two analog inputs (two multi-function and one reference) for the
external input of numerous references and limits.
Parameter
Code Name Function Range
Initial
Value
Access
Level
H03.01 Terminal A1 Signal Select Voltage for Terminal A1 analog
input signal
00 00 Basic/Adv
00 0VDC to 10VDC
H03.02 Terminal A1 Select Assigns one of the following
functions for the analog input
Terminal A1.
00–1F 00 Basic/Adv
00 Frequency Bias Basic
01 Frequency Gain Adv
02 Aux Speed Reference 1 Adv
03 Aux Speed Reference 2 Adv
04 Output Voltage Bias Adv
07 OT/UT Detection Level Overtorque Detection Level Adv
0E Motor Temperature Used in conjunction with L01.03,
L01.04 and L01.05
Adv
0F Not used Not Used Basic/Adv
10 Forward Torque Limit Adv
11 Reverse Torque Limit Adv
12 Regen Torque Limit Adv
15 FWD/REV Torque Limit Adv
1F Not Used Not used Adv
H03.03 Terminal A1 Gain Gain multiplier for Terminal A1
analog input signal
-999.9 –
999.9%
100.0 Basic/Adv
H03.04 Terminal A1 Bias Bias multiplier for Terminal A1
analog input signal
-999.9 –
999.9%
000.0 Basic/Adv
