IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-15
NOTE: Assume the constant B03.03 is set to “00” (Decel to Stop).
Figure 5-13: Normal Accel/Decel Time and Multiple Accel/Decel Changeover
Jump Frequencies
This function allows the “jumping” of critical frequencies so that the motor can operate without
resonant vibrations caused by some machine systems. This function is also used for deadband
control. Setting the value to 0.0 Hz disables this function.
Run Command
MFI=1A
Accel/Decel
Changeover
Frequency Output
Brake Output
B05.04
B05.02
B05.03
B05.01
B05.01
B05.02
Parameter
Code Name Function Range Initial Value
Access
Level
B08.01 Jump Frequency 1 First of three jump frequencies. 0.0–150.0 Hz 0.0 Adv
B08.02 Jump Frequency 2 Second of three jump frequencies. 0.0–150.0 Hz 0.0 Adv
B08.03 Jump Frequency 3 Third of three jump frequencies. 0.0–150.0 Hz 0.0 Adv
B08.04 Jump Bandwidth Jump frequency reference bandwidth. 0.0–20.0 Hz 1.0 Adv
