IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-17
Quick Stop
The Quick Stop Function provides an automatic Alternate Deceleration at Stop Command.
NOTE: The Quick Stop Deceleration time differs from the normal deceleration time and is applied
only when the RUN command is removed.
Figure 5-14: Quick Stop
Parameter
Code Name Function Range Initial Value
Access
Level
C01.01 Quick Stop 0/1 Determines whether Quick
Stop is enabled
00–01 00* Basic/Adv
00 Disabled
01 Enabled
C01.02 Quick Stop Time Deceleration time during
Quick Stop function.
0.0–25.5 sec 1.0 Basic/Adv
* Initial value is determined by X-Press Programming (Table 4.1 to 4.2).
