Magnetek 2001-G+M - Fault Trace; Fault History

IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-90
Fault Trace
Fault History
Parameter
Code Name Function Units
Access
Level
U02.01 Current Fault Displays the most recent fault detected before being reset -- Basic/Adv
U02.02 Last Fault Displays the most recent fault after being reset (same as
U03.01)
-- Basic/Adv
U02.03 Frequency Reference @
Fault
Freq ref when fault was detected Hz Basic/Adv
U02.04 Output Frequency @
Fault
Output freq when fault was detected Hz Basic/Adv
U02.05 Output Current @ Fault Output current when fault was detected A Basic/Adv
U02.06 Motor Speed @ Fault
(OLV Only)
Motor speed when fault was detected Hz Adv
U02.07 Output Voltage @ Fault Output voltage when fault was detected V Basic/Adv
U02.08 DC Bus Voltage @ Fault DC Bus voltage when fault was detected V Basic/Adv
U02.09 Output Power @ Fault Output power when fault was detected kW Basic/Adv
U02.11 Input Terminal Status @
Fault
Input terminal status when fault was detected -- Basic/Adv
U02.12 Output Terminal Status @
Fault
Output terminal status when fault was detected -- Basic/Adv
U02.13 Operation Status @ Fault Inverter status before fault was detected -- Basic/Adv
U02.14 Elapsed Time @ Fault Elapsed time when fault was detected hr Basic/Adv
U02.15 Speed Reference During
Soft Start @ Fault
Speed reference during soft start at previous fault % Basic/Adv
U02.16 Motor q-Axis Current
During Fault
--- -- Adv
U02.17 Motor d-Axis Current
During Fault
--- -- Adv
Parameter
Code Name Function Units
Access
Level
U03.01 Last Fault Displays most recent fault detected -- Adv
U03.02 Fault Message 2 Displays second most recent fault -- Adv
U03.03 Fault Message 3 Displays third most recent fault -- Adv
U03.04 Fault Message 4 Displays fourth most recent fault -- Adv
U03.05 Fault Message 5 Displays fifth most recent fault -- Adv
U03.06 Fault Message 6 Displays sixth most recent fault -- Adv
U03.07 Fault Message 7 Displays seventh most recent fault -- Adv
U03.08 Fault Message 8 Displays eighth most recent fault -- Adv
U03.09 Fault Message 9 Displays ninth most recent fault -- Adv
U03.10 Fault Message 10 Displays tenth most recent fault -- Adv
U03.11 Elapsed Time 1 Elapsed time of most recent fault -- Adv
U03.12 Elapsed Time 2 Elapsed time of second most recent fault -- Adv
U03.13 Elapsed Time 3 Elapsed time of third most recent fault -- Adv
U03.14 Elapsed Time 4 Elapsed time of fourth most recent fault -- Adv
U03.15 Elapsed Time 5 Elapsed time of fifth most recent fault -- Adv
U03.16 Elapsed Time 6 Elapsed time of sixth most recent fault -- Adv
U03.17 Elapsed Time 7 Elapsed time of seventh most recent fault -- Adv
U03.18 Elapsed Time 8 Elapsed time of eight most recent fault -- Adv
U03.19 Elapsed Time 9 Elapsed time of ninth most recent fault -- Adv
