Magnetek 2001-G+M - Maintenance; Motor Control Monitor

IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-91
Maintenance
U03.20 Elapsed Time 10 Elapsed time of tenth most recent fault -- Adv
U03.21 Accumulated Operations Displays the number of FWD and REV commands -- Adv
U03.22 U03.21 Rollovers Increments when U03.21 reaches 65535. U03.21 is set to
zero.
-- Adv
U03.23 Overload/Load Check
Count
Displays the number of OL1, OL2 and LC faults -- Adv
Parameter
Code Name Function Units
Access
Level
U04.01 Elapsed Time Cumulative operation time of drive. Defined by O03.02 hr Adv
U04.03 Cooling Fan Operation
Time
Cumulative operating time of cooling fan. hr Adv
U04.04 Cooling Fan Maintenance % Adv
U04.05 Capacitor Maintenance % Adv
U04.06 Soft Charge Bypass Relay
Maintenance
%Adv
U04.07 IGBT Maintenance % Adv
U04.08 Heatsink Temperature °C Adv
U04.09 LED Check Lights all segments of the LED to verify that the display is
working properly.
U04.10 kWh; Lower 4 Digits kWh Adv
U04.11 kWh; Upper 5 Digits kWh Adv
U04.12 CPU Resources Used -- Adv
U04.13 Peak Hold Current -- Adv
U04.14 Peak Hold Output
Frequency
-- Adv
U04.16 Motor Overload (oL1)
Detection Level
-- Adv
U04.17 Motor Overload (oL2)
Detection Level
-- Adv
U04.18 Frequency Reference
Source Selection
-- Adv
U04.19 Frequency Reference
Memobus
-- Adv
U04.20 Output Frequency
Reference (decimal)
-- Adv
U04.21 Run Command Selection
Results
-- Adv
U04.22 Memobus
Communication
Reference
-- Adv
U04.23 Not Used -- Adv
Motor Control Monitor
Parameter
Code Name Function Units
Access
Level
U06.01 Motor Secondary Current
(lq)
%Adv
U06.02 Motor Excitation Current
(ld)
%Adv
Parameter
Code Name Function Units
Access
Level
