IMPULSE•G+ Mini Advanced Instruction Manual - March 2014
1-7
460V Class
IMPULSE•G+ Mini External Resistor Specifications
If Magnetek resistors are not used, this table should be used to determine the minimum resistance
values.
Model Number 460 V Part Number Maximum Amps of Reactor
4001-G+M REA460-1 2
4002-G+M REA460-1 2
4003-G+M REA460-2 4
4004-G+M REA460-3 4
4009-G+M REA460-5 8
4014-G+M REA460-7.5 12
4018-G+M REA460-10 18
4024-G+M REA460-15 25
4031-G+M REA460-20 35
IMPULSE•G+
Mini
Traverse Hoist w/ Mechanical Load Brake
Resistor Part No. Resistance Resistor Part No. Resistance Resistor Part No. Resistance
Model Number CMAA Class A, B, C  CMAA Class D  CMAA Class A, B, C, D 
230 Volts
2001-G+M EDB2001CT 220 EDB2001DTP 220 EDB2001CT 220
2003-G+M EDB2001CT 220 EDB2001DTP 220 EDB2001CT 220
2005-G+M EDB2003CT 110 EDB2004DTP* 100 EDB2003CT 110
2008-G+M EDB2006CT 58 EDB2006DTP* 44 EDB2003CT 110
2011-G+M EDB2009CT 37 EDB2011DTP* 31 EDB2006CT 58
2017-G+M EDB2015CT 25 EDB2015DTP* 25 EDB2009CT 37
2025-G+M EDB2022CT* 14 EDB2022DT* 14 EDB2015CT 25
2033-G+M EDB2028CT* 13 EDB2028DT* 12 EDB2015CT 25
2047-G+M EDB2042CT* 7.8 EDB2042DT* 6.5 EDB2022CT* 14
2060-G+M EDB2054CT* 6 -- 4.8 EDB2028CT* 13
460 Volts
4001-G+M EDB4001CT 440 EDB4001DTP 440 EDB4001CT 440
4002-G+M EDB4001CT 440 EDB4002DTP* 354 EDB4001CT 440
4003-G+M EDB4003CT 230 EDB4004DTP* 187 EDB4001CT 440
4004-G+M EDB4004CT 150 EDB4005DTP* 133 EDB4003CT 230
4009-G+M EDB4007CT 100 EDB4008DTP* 84 EDB4004CT 150
4014-G+M EDB4011CT* 59 EDB4011DT* 47 EDB4007CT 100
4018-G+M EDB4014CT* 46 EDB4014DT* 37 EDB4007CT 100
4024-G+M EDB4021CT* 31.1 EDB4021DT* 24.9 EDB4011CT* 59
4031-G+M EDB4027CT* 24.2 EDB4027DT* 22 EDB4014CT* 46
* Resistors are supplied in vented indoor enclosure.
