IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
4-14
Select Motion (A01.03)
Set this parameter to match the motion of application. See tables 4.1 and 4.2 (X-Press Programming)
for details.
Speed Reference (A01.04)
This parameter will automatically define the input terminals for the selections listed below. See
tables 4.1 and 4.2 (X-Press Programming) for details.
Setting Description Access Level
00 Traverse - Decelerate to stop upon removal of RUN command. Basic/Adv
01 Standard Hoist - Immediate stop upon removal of RUN command Basic/Adv
04 Braketronic Adv
Setting Description Access Level
00 2-SPD Multi-step — Defines Terminal S3 = 2nd speed. Basic/Adv
01 3-SPD multi-step — Defines Terminals S3 and S4 as speeds 2 and 3
respectively.
Basic/Adv
02 5-SPD Multi-step — Defines Terminals S3-6 as speeds 2-5. Basic/Adv
03 2-Step infinitely variable — Terminals S1 and S2 = B01.01 (Reference 1) and
speed hold. Terminal S3 = Accelerate.
Basic/Adv
04 3-Step infinitely variable — Terminals S1 and S2 = B01.01 (Reference 1).
Terminal S3 = Speed Hold. Terminal S4 =Accelerate.
Basic/Adv
05 Uni-polar analog — Terminals S1 and S2 = A directional input. Terminal A1 =
0-10V. Terminal A2 = 4-20mA for speed reference.
Basic/Adv
