Magnetek 2001-G+M - Page 55

IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
4-17
Parameters Changed by X-Press Programming
Table 4-3: Braketronic (A01.03 = 04)
A01.04 Description
C01.01 D09.01 D09.02 D09.03 E01.03 H01.01 H01.02 H01.03 H01.04 H01.05 H01.06 H01.07 H02.01 H02.02 H02.03 H03.01 N02.05
Quick
Stop
S-Curve
Accel at
Start
S-Curve
Accel at
End
S-Curve
Decel at
Start
V/f
Selection
Terminal
S1
Select
Ter minal
S2
Select
Ter minal
S3
Select
Terminal
S4
Select
Terminal
S5
Select
Ter minal
S6
Select
Terminal
S7
Select
Ter minal
MA/MB/MC
Select
Ter minal
P1
Select
Terminal
P2
Select
Ter minal
A1
Signal
OLV Stab.
Level
00 2-Speed Multi-Step 00 0.00 0.00 0.00 00 80 81 00 0F 0F 0F 65 0F 0F 0F 00 00
01 3-Speed Multi-Step 00 0.00 0.00 0.00 00 80 81 00 01 0F 0F 65 0F 0F 0F 00 00
02 5-Speed Multi-Step 00 0.00 0.00 0.00 00 80 81 00 01 02 03 65 0F 0F 0F 00 00
03 2-Step Infinitely Variable 00 0.00 0.00 0.00 00 80 81 05 0F 0F 0F 65 0F 0F 0F 00 00
04 3-Step Infinitely Variable 00 0.00 0.00 0.00 00 80 81 04 05 0F 0F 65 0F 0F 0F 00 00
05 Uni-Polar Analog 00 0.00 0.00 0.00 00 80 81 0F 0F 0F 0F 65 0F 0F 0F 00 00
A01.04 Description
B01.01 B01.02 B01.03 B01.04 B01.05 B01.17 B01.18 B02.03 B03.03 B05.01 B05.02
Speed
1
Speed
2
Speed
3
Speed
4
Speed
5
Jog Ref Ref Priority
Ref. Lower
Limit
Stopping
Method
Accel Time 1 Decel Time 1
00 2-Speed Multi-Step 6.00 60.00 0.00 0.00 0.00 6.00 02 2.0 00 1.0 1.0
01 3-Speed Multi-Step 6.00 30.00 60.00 0.00 0.00 6.00 02 2.0 00 1.0 1.0
02 5-Speed Multi-Step 6.00 15.00 30.00 45.00 60.00 6.00 02 2.0 00 1.0 1.0
03 2-Step Infinitely Variable 6.00 0.00 0.00 0.00 60.00 6.00 02 2.0 00 1.0 1.0
04 3-Step Infinitely Variable 6.00 0.00 0.00 0.00 60.00 6.00 02 2.0 00 1.0 1.0
05 Uni-Polar Analog 0.00 0.00 0.00 0.00 0.00 6.00 02 2.0 00 1.0 1.0
