Malaguti Password 250 i.e. - Rear Shock Absorbers

100
A
FRAME AND RUNNING GEAR
DISASSEMBLY
11/06
PASSWORD 250 i.e.5
REAR SHOCK ABSORBERS
Before removing the rear shock absorbers
support the centre of the frame to prevent
the scooter from falling.
• First undo lower screw (Va); then upper screw (Vb).
• Remove shock-absorber (A).
Va
24 ± 15%
Vb
A
Va
Vb
45 ± 15%
