Malaguti Password 250 i.e. - Centre Stand

78
A
FRAME AND RUNNING GEAR
DISASSEMBLY
11/06
PASSWORD 250 i.e.5
A
C
D
B
CENTRE STAND
Prop up the centre of the scooter to prevent
it from falling.
• Detach two springs (A).
• Remove snap ring (B), washer (C) then remove pin (D).
When reassembling, ALWAYS insert washer
(C) UNDER the snap ring.
