PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
DISASSEMBLY
5
V2
30 ± 20%
V2
V
10 ± 15%
V
SPEEDOMETER SENSOR
• Undo screw (V) ensuring the spacer does not fall.
• Disconnect the electronic transmission connector (See
“Systems” section).
When refitting, use a feeler gauge to check
that the sensor - disc gap is 1¸2 mm.
• Remove the sensor complete with the transmission.
FRONT BRAKE CALIPER
• Undo screws (V2) and free the complete caliper.
When refitting, insert the longest screw in
the top fitting.
