Malaguti Password 250 i.e. - Front Fairing

53 11/06
A
PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
DISASSEMBLY
5
• (Remove upper handlebar cover).
• Undo screw (V) and remove counterweight.
• Undo screws (V2) and remove LH control.
Use compressed air to reduce friction when
removing and refitting the twist grip.
FRONT FAIRING
• Undo screws (V2).
• Undo screws (V2).
V2
V2
V
V2
